bbraun Infusomat Compactplus P - Power Supply

3 Disassembly / Assembly
Infusomat® compact
plus
P 1.0 3 - 23
EN
For internal use, only
3. Remove five screws (Fig. 3 - 29 / Item 1) using a 15IP TORX
plus screwdriver.
4. Remove the housing front (Fig. 3 - 30 / Item 1) from the
housing, bottom part (Fig. 3 - 30 / Item 2).
Fig. 3 - 29
1 Screw DELTA PT 35x10 WN 5451
1
Fig. 3 - 30
1 Housing front
2 Housing, bottom part
2
1
