Incubation Specifications
CO
2
consumption <1Kg//24hr (for 5% CO
2
(± 1%) at 35 °C
Incubation atmosphere O
2
or CO
2
Temperature range 30–40 °C, ± 1 °C
Plate Specifications
Height, including lid 13.0–16.2 mm
Diameter of bottom 85–91 mm
Diameter of lid
89–93 mm (when using two or more different kinds of plates, the
difference between lid diameters should not exceed 2 mm)
Top rim Shape: parallelogram with rounded corners
Bottom rim
Shape: parallelogram with rounded corners
Maximum one opening in the rim
No “fin” (when using bi-plates) inside the rim
Lid vents Preferably three or more
Weight Minimum (empty): 14 g / Maximum (full): 40 g
Agar thickness 3–7 mm
For optimum performance, use the same type of plates.
Camera Specifications
Aperture F12 fixed
Camera type High Speed CMOS Image Sensor - Python 25K
Image resolution 5,120 x 5,120 pixels
Lens type Bi-Telecentric lens
Sensor type Python xK CMOS image sensor
Working distance 175 ± 8 mm
77
9 - Installation requirements
