9.1 Module specifications
Physical Dimensions Width Depth Height Weight
BDKiestra™ ReadA 1,000 mm 1,640 mm 2,330 mm 690 kg
Clearance of 1,200 mm is needed on the door side
Utility Requirements
Compressed air
1
External supply of minimum 8 Bar to maximum 10 Bar, minimum
250 L/min.
Transient overvoltage
category
Cat II
Voltage 100-240 V, 50/60 Hz, 1N~ or 2~
Voltage fluctuations ± 10% of the nominal voltage
1
Constant capacity, free of moisture and oil, minimum of class 4 (ISO 8573-1)
CAUTION
Only use the BD supplied power cord to connect
the module.
Module Operating Requirements
Audible Noise
1
<60 dB
Power consumption 900 W
Thermal dissipation
2,800 BTU/hr max
1,200 BTU/hr average
1
Measured at 1 meter from surface of instrument, averaged over 30 seconds
Environmental Requirements
Altitude 0-2,000 m
Ambient humidity 20–80% RH (non-condensing)
Ambient temperature
1
18–27 °C
Pollution degree 2
1
The product is tested and is compliant to safety standards IEC/EN/UL 61010, applicable for this laboratory instrument. The
standards require a safe situation for operator and the laboratory environment when the product is used to a maximum ambient
temperature of 40°C. This instrument meets this safety clause so there will be no hazardous situation for user and environment.
However, the instrument microbiological results and performance (the IVD intended use) is only guaranteed if the instrument is used
within an ambient temperature of 18°C to maximum 27°C.
Storage Conditions
Humidity 20-80% RH (non-condensing)
Temperature -10°C – 40°C
