1. Introduction - Overview
1-6
CONTROL PANEL: DISPLAY AND KEYS
The control panel consists of the touch screen display, which incorporates a bright
graphical display with touch pad keys. The display shows status and alarm messages at
the top and middle, and contains the touch keys at the bottom.
CONTROL PANEL SUMMARY
Status Display:
• Flow Rate in ml/min
• Volume Infused
• Infusate Temperature in ºC
• Pressure in the Fluid Line in mmHg
• Bolus Volume (when infusion of a
fixed bolus of fluid is desired).
Function Keys: The keys that control all system functions are displayed on
the screen. The screen is changed each time a function key
is pressed. Only keys that are relevant to the desired
function are presented. The active key is highlighted.
There are three (3) different levels of sensitivity: Fast,
Medium, and Slow. The key sensitivity is set at the factory to
medium, but can be adjusted by the operator in SERVICE
MODE.
See Chapter 6 for ‘Key Rate’ sensitivity setup.
Alarm Display: Graphical alarm messages indicating where errors have
occurred and suggested operator action.
