5. Removal and Replacement of Major Components and Modules
5-65
U. OUTPUT TEMPERATURE PROBE (Reference Drawing: 403-00107)
Removal
1. Remove Pump Motor. (See Step V.)
2. Unplug Output Temperature Probe Cable, JP8, from Daughter
PCB.
3. Use an Exacto knife to cut through the silicone on the front of the
temperature probe.
4. Remove 2X pan head Phillips screws attaching Output
Temperature Probe to Support Housing. Gently push probe out
from the inside.
Installation
1. Insert Output Temperature Probe into Support Housing with the
sensor window facing the center of the Housing. Apply RTV
silicone to entire back surface and screw holes.
2. Reinstall 2X pan head Phillips screws.
3. Apply a bead of silicone around the outside perimeter of Output
Temperature Probe and allow silicone to dry for at least 1 hour.
4. Twist cable then reattach Output Temperature Probe Cable to
Daughter PCB.
5. Reinstall Pump Motor. (See Step V.)
6. Perform the Output Temperature probe verification, Chapter 7.
