5. Removal and Replacement of Major Components and Modules
5-63
S. INPUT TEMPERATURE PROBE (Reference Drawing: 403-00107)
Removal
1. Remove the Instrument Cover. (See Step A Removal, 1 – 7.)
2. Unplug Input Temperature Probe Cable, JP15, from Daughter
PCB.
3. Remove 2X pan head Phillips screws attaching Input Temperature
Probe to Support Housing.
4. Cut through silicone and remove Input Temperature Probe.
Installation
1. Insert Input Temperature Probe into Support Housing with the
sensor window facing the center of the Housing. Apply RTV
silicone to entire back surface and screw holes.
2. Reinstall 2X pan head Phillips screws.
3. Apply a bead of silicone around the outside perimeter of Input
Temperature Probe and allow silicone to dry for at least 1 hour.
4. Twist cable then reattach Input Temperature Probe Cable to
Daughter PCB.
5. Reinstall the instrument cover. (See Step A Installation, 1 - 5.)
6. Perform the Input Temperature probe verification. See Chapter 7.
