Belmont FMS2000 - Installing the 3.0 Liter Reservoir

3. Operation & System Set-up
3-19
INSTALLING THE 3.0 LITER RESERVOIR
Connect 3.0 L Reservoir to the 3-
Spike Disposable Set
1. Using aseptic techniques, remove the standard fluid supply from the 3-spike
disposable set by disconnecting the luer connectors.
• Completely clamp off the larger pump tubing.
• Disconnect the larger pump tubing by pressing in the luer lock tab and
pulling the connector out.
• Disconnect the thinner recirculate line by unscrewing the connector.
2. Assemble the 3.0 L Reservoir using aseptic techniques by first attaching the
three fluid supply tails onto the top of the reservoir.
3. Connect the 3.0 L Reservoir to the luer of the 3-spike disposable set.
Disconnect Standard Fluid Supply
