What to do if my Belmont Industrial Equipment powers off immediately after switching it on?
If your Belmont Industrial Equipment powers off immediately after switching it on, power down and service the machine. This may be caused by shorted IGBT’s on Driver ‘A’ and ‘B’ or the EPROM not being seated properly in the socket.
What to do if the Belmont Industrial Equipment displays 'HIGH PRESSURE'?
If the Belmont Industrial Equipment displays 'HIGH PRESSURE', ensure the flow path isn't blocked and that the recirculate line isn't obstructed. Verify the infusion site is well-placed and you're using the appropriate infusion set. You can also increase the pressure limit setting. This issue may arise because the patient line or recirculate line is blocked, the infusion site is not well placed, the catheter bore size is too small, or the pressure limit setting is too low.
What to do if the Belmont Industrial Equipment displays 'DOOR OPEN'?
If the Belmont Industrial Equipment displays 'DOOR OPEN', close the door to silence the alarm and resume operation. Check the magnet in the door latch. The alarm occurs because the door is open or there is no magnet in the door latch. If the door is opened while the system is pumping, the system will immediately stop heating and pumping, the valve moves to the recirculate position and an audible alarm sounds.
What to do if the Belmont Industrial Equipment displays 'HEATING FAULT'?
If the Belmont Industrial Equipment displays 'HEATING FAULT', check the disposable set and flow path for any blockages. Ensure the windows on the disposable set and the IR probes are clean and dry; clean them with a moistened soft cloth if necessary, and dry them before continuing. Press RETRY to continue. If the error persists, power down the system and service the machine. This fault can occur due to wet, dirty, or blocked disposable set windows, a wet, dirty, or blocked IR probe, an IR probe failure, or a heater fault.
What to do if I am unable to calibrate temperature probes on my Belmont Industrial Equipment?
If you are unable to calibrate temperature probes on your Belmont Industrial Equipment, check the temperature of the fluid and make certain it is correct. If the problem persists, service the machine. This issue can occur due to temp probe malfunction or incorrect fluid temperature used for calibration.
What to do if the Belmont Industrial Equipment displays 'FLUID OUT'?
If the Belmont Industrial Equipment displays a 'FLUID OUT' message, first press MUTE to silence the alarm. Check if the equipment is out of fluid, and if so, add more fluid and press REPRIME. Ensure the bag clamps are fully opened and the bag is properly spiked. Check that the tubing in the fluid out sensor is correctly seated and not stretched. If the reservoir chamber stays empty during reprime, the air vent filter may be clogged; pierce the fluid bag(s) with bag spikes and fully open clamps to allow the air in the reservoir chamber to escape into fluid bag(s) and allow fluid to fill the reservoir chamber. If the coarse blood filter is clogged, replace the reservoir chamber or disposable. If the problem persists, power down and service the machine. The issue may arise because of the equi...
What to do if the Belmont Industrial Equipment displays 'VALVE FAULT'?
If the Belmont Industrial Equipment displays 'VALVE FAULT', check that the valve is not blocked. Restart the system and try again. If the error persists, power down and service the machine. This could be due to valve failure or a valve position sensor malfunction.
What to do if the Belmont Industrial Equipment displays 'WATCH DOG'?
If the Belmont Industrial Equipment displays 'WATCH DOG', restart the system. If the error persists, service the machine. This indicates an internal computer malfunction.
What to do if the Belmont Industrial Equipment displays 'PUMP FAULT'?
If the Belmont Industrial Equipment displays 'PUMP FAULT', verify that the pump tubing is correctly seated on the pump head and that the pump turns freely and the head is clean. Press Retry to try again. If the error persists, power down and service the machine. This fault may be caused by incorrectly installed pump tubing, pump failure, pump speed feedback encoder failure, or the pump running out of control.
What to do if the Belmont Industrial Equipment displays 'POWER MODULE OVERTEMP'?
If the Belmont Industrial Equipment displays 'POWER MODULE OVERTEMP', ensure the fan air vents at the bottom of the machine are not blocked. Wait for the unit to correct the problem; the display will return to the Infuse screen when the error clears. Press MUTE to silence the alarm. If the error persists, power down and service the machine. This occurs when the power driver module is overheating.
System overview, infusion capabilities, warming, monitoring, and safety features.
Details system components: Control System, Disposable Set, and major parts.
Visual representation of main components and their interconnections.
Describes the peristaltic pump design, control, cleaning, and mounting.
Explains the fluid warming mechanism, sensors, and temperature control.
Details the pressure sensor function, limits, alarms, and safety features.
Covers types of air detectors, their location, and alarm conditions.
Describes the function, operation modes, and safety role of the diversion valve.
Explains system alarms, responses, and required user intervention.
Details the touch screen display and function keys interface.
Specifies the physical size and weight of the FMS2000 unit.
Covers options for carrying and mounting the unit, including IV pole compatibility.
Details electrical specifications including input voltage, fuse, and power.
Provides battery type, running time, and recharge time details.
Lists operating and storage temperatures, humidity, pressure, and vibration limits.
Details flow rate ranges, output temperature, heating capacity, and modes.
Describes control panel features, display area, status, and function keys.
Explains monitoring of infusate temperature, line pressure, and air detection.
Lists alarm messages for operator settings and system failures.
Details electrical safety, ingress protection, and medical equipment classifications.
Explains standard symbols used in the manual and on the device.
A summary of major steps for operating the FMS2000, from setup to shutdown.
Instructions for securely mounting the FMS2000 on an IV pole.
Detailed steps for connecting the disposable set components.
Procedures for connecting the 3.0 L reservoir to the disposable set.
Steps for connecting power, turning on the system, and initial checks.
Steps for priming the main system and patient line with compatible fluids.
Procedures for making the patient connection using aseptic technique.
Explanation of the interface, controls, and status displays.
Details on starting infusion, automatic warming, and pressure control.
Describes how the system automatically removes air during infusion.
Procedure for delivering a fixed volume bolus of fluid with warming.
Using the RECIRC key to recirculate fluid for warming and air removal.
System behavior and recovery after accidental power interruption.
Steps to safely stop and prepare the system for removal or cleaning.
Using the system on battery power, limitations, and low battery indication.
Procedure for restarting the system after a power cycle.
Method for manual fluid infusion during system failure.
Diagram showing major module connections within the system.
Description of the power module components and their functions.
Details on the daughter board's circuitry and connected components.
Explanation of the computer board's components and operation.
Function and conversion capabilities of the AC/DC power supply board.
Overview of other system components like heater, pump, and sensors.
List of tools and materials needed for component removal and replacement.
Procedures for replacing the instrument cover and membrane panel.
Guides for replacing PCBs like AC/DC, CPU, Daughter, Driver, and EMI Filter.
Procedures for replacing sensors and detectors like air, fluid, temperature, and pressure.
Steps for removing and installing the pump motor and valve motor/pincher.
Guides for replacing the battery, circuit breaker, IEC connector, and power driver module.
Procedures for replacing components like C152, EPROM, ceramic disk, and fan guard.
How to adjust date/time, display brightness, key sensitivity, and bolus volume.
Procedures for setting the system's date and time.
Adjusting screen brightness and touch key sensitivity.
Setting bolus volume and configuring high pressure alarm limits.
Overview of required hardware calibrations and necessary materials.
Step-by-step guide to calibrate the pressure transducer.
Procedures for calibrating the system's temperature probes.
Steps to calibrate the power module and pump speed.
Safety precautions before performing maintenance or checks.
Outlines routine and periodic maintenance schedules.
Steps for cleaning exterior, detectors, power cord, probes, and guards.
Guide for visually inspecting the unit's components and external condition.
Step-by-step functional checks of the system's operation.
Procedure to test the system's battery operational duration.
Steps for performing earth and patient leakage current tests.
Verifying operation of key hardware components like valve, detectors, and sensors.
Verifying the accuracy of the system's temperature probes.
Steps to verify the accuracy of the pressure transducer.
Instructions for removing and cleaning the pump head.
Reference to Chapter 5 for pump motor removal and installation.
Reference to Chapter 5 for valve motor removal and installation.
Checklist for recording results of visual inspection and operational checks.
Precautions and guidance regarding EMC for medical electrical equipment.
Overview of alarm conditions and troubleshooting procedures for the FMS2000.
Describes the air detection alarm, its causes, and corrective actions.
Explains the door open alarm, its response, and how to clear it.
Details the fluid out alarm, causes, and steps to resolve it.
Procedure to reprim main system when reservoir is empty after operation.
Troubleshooting persistent fluid out alarms after extensive use.
Instructions for safely replacing the reservoir chamber.
Explains the high pressure alarm, its causes, and actions to take.
Describes the low battery alarm and charging procedure.
Explains the missing disposable alarm and how to clear it.
Table detailing operational alarms, causes, responses, and operator actions.
Details on heating fault and over temperature alarms and their solutions.
Explains hardware-related alarms like detector, heater, and power module faults.
Addresses issues like battery no heating, dim display, slow flow rate, and keypad problems.
Details on ordering replacement parts and circuit boards for the FMS2000.
Contact details for ordering FMS2000 parts and assemblies.
Warranty terms and conditions for the FMS2000.
General| Brand | Belmont |
|---|---|
| Model | FMS2000 |
| Category | Medical Equipment |
| Language | English |
