5. Removal and Replacement of Major Components and Modules
5-52
H. CERAMIC DISK (DISH HEATER) (Reference Drawing 403-00109)
Removal
1. Remove Door Assembly from Support Housing, by pulling upward.
2. Place a protective covering over Cover and lay Door Assembly
face down on a flat surface.
3. Cut through silicone around Ceramic Disk.
4. Remove Ceramic Disk and Disk Gasket.
Installation
1. Remove one side of the protective covering from Disk Gasket.
2. Press the Disk Gasket onto the center of Ceramic Disk.
3. Remove the other protective covering from the Disk Gasket.
4. Place Ceramic Disk, with the Disk Gasket side down, into the
cutout in the Door. (Do not allow the walls of the Door to touch the
Ceramic Disk.)
5. Apply a thin bead of silicone around entire perimeter of Ceramic
Disk and allow at least 1 hour for silicone to dry.
6. Replace Door Assembly into the Support Housing, making sure
the door is pushed all the way down.
