Belmont tbCompass - Handpiece; Handpiece Priority Function (First Priority); Handpiece Air Pressure Gauge

18
DESCRIPTION OF OPERATION AND FUNCTIONS OF COMPONENTS
No.1
ERR
Holder Type
Place Type
Foot Controller
Handpiece
Handpiece is
activated when
the pedal is
depressed
Handpiece Pressure Gauge
Handpiece
Support Arm
Doctor Table
Instrument Holder
Handpiece
• The handpiece is actuated by picking it up from the
instrument holder and operating the foot controller.
See pages 26 for operation of foot controller, micromotor and
electric scaler.
+DQGSLHFHSULRULW\IXQFWLRQ¿UVWSULRULW\
Only one handpiece, which was picked up first of all, is
operable. The holder No. of the operable handpiece is
displayed on the indicator.
If multiple handpieces are picked up in succession from the
holder, and the handpiece that was picked up ¿UVW is returned
to the holder, error display [ERR] appears on the indicator.
If error display appears, the normal state will be restored
ZKHQDOOWKHKDQGSLHFHVDUH¿WWHGLQWKHKROGHr.
Handpiece air prHVVXre gauge
Displays the handpiece drive air pressure.
Do noWDGMXVWWKeKRlderVXSSRrt arm and iQVWrument
KROGHr. %HFDXVH WKH angle DGMXVWPHQW of WKH KROGHr LV
¿xed at tKH point of LQVtallation, tKH Kolder VXSSort
DUPZLOOEHGDPDJHGLQFDVHLWLVPRYHGWRRKDUG
NOTICE
Operation of WKe eacK KandpieceV, pleaVe refer to
WKe appendix for optional KDQGSiece operating
LQVWUXFWLRQV
2 Doctor Unit Section
CAUTION
