DESCRIPTION OF OPERATION AND FUNCTIONS OF COMPONENTS
5 Dental Light Section
300LED dental light
(Type AL-320PAS)(Optional)
Main switch and operation switch
When the main switch of the dental unit is turned on, the
dental light power also turned on.
The dental light may be turned on and off with the touchless
switch or the dental light switch on the operation panel
of the unit side.
Turning on and off of the light by the touch-less
switch
The light can be turned on/off with a touchless sensor.
(Effective sensing area is 65mm depth, 15mm width). Pass
your hand by touchless sensor within effective sensing area
to turn on and pass your hand again to turn off.
* If the surface of a touchless switch becomes unclean, this
may affect the sensitivity of the sensor.
Please wipe the surface of a touchless switch with a soft
cloth.
Intensity control volume
It can adjust intensity between 3,100 ~ 28,000lx by stepless
LQWHQVLW\FRQWUROYROXPHDVOHIW¿JXUH
The intensity is increased by turning intensity control
volume clockwise. It is decreased by turning the intensity
control volume counterclockwise.
'XULQJFRPSRVLWHPRGHLQWHQVLW\FDQWEHDGMXVWHG
Changing into composite mode
During normal treatment mode, while the light is on, place
and hold your hand by touchless sensor within effective
sensing area for certain time or keep pressing dental light
switch on the control panel for certain time. The light
intensity will be automatically reduced to the composite
mode. To switch back to the normal treatment mode, place
your hand by the touchless sensor for certain time again or
keep pressing dental light switch on the control panel
for certain time.
* When the light is turned off in the composite mode, it goes
on in the normal treatment mode when it is turned on again.
Intensity control
volume
Touch-less
sensor
Reaction distance
Approx. 65 mm or less
Intensity control
volume
15mm (Effective sensing area)
LOW
High
(Increase)(Decrease)
35
