29
DESCRIPTION OF OPERATION AND FUNCTIONS OF COMPONENTS
4 Cuspidor Unit Section
maintenance panel
㹌
㸶
Assistant panel
Knurlet-screw
Maintenance Panel & Cuspidor Control Panel
Standard Package / Cuspidor Package
The cuspidor maintenance panel can be opened outward by loosen the knurlet-screw from bottom of the cuspidor unit.
Vacuum Package
1 Dental light select switch
• This switches changes the lighting mode (SENSOR, MANUAL, OFF) of the dental light.
* There are cases where this switch cannot be used unit specification and the type of dental light.
• SENSOR Mode (Right side) : The dental light can be turned on/off with a touchless switch.
• MANUAL Mode (Left side) : The dental light can be turned on without touchless switch.
• OFF Mode (Center) : The dental light can be off.
To Next Page
