Alarm messages
74
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
11. Alarm messages
Alarm message Description Action LED indicators Alarm 1 (insulation fault)
The insulation resis- tance is lower than the response value R
an1
• Determine cause of the insulation fault and elimi-
nate it.
ALARM 1 lights up
Alarm 2 (insulation fault)
The insulation resis- tance is lower than the response value R
an2
• Determine cause of the insulation fault and elimi-
nate it.
ALARM 2 lights up
Check L1-L2 for correct connection
Connection fault sys- tem
• Check the wiring of terminals L1/+, and L2/- to
the IT system
• Press the TEST button • Check mains voltage • Check fuses
ALARM 1 + ALARM 2 flash in common mode
Check E-KE connec- tions for interrup- tions
Connection fault. E/KE not connected to PE
• Check wiring of terminals E and KE to earth (PE) • Press the TEST button
ALARM 1 + ALARM 2 flash in common mode
Device error x.xx Internal device error
• Press the TEST button • Switch the supply voltage on and off •Contact Bender Service
SERVICE lights up
Overtemperature coupling
Overtemperature cou- pling terminal L1/+ or L2/–
• Check mains voltage level and eliminate any exis-
ting insulation faults. After cooling down, the device switches on again automatically at a tem- perature of 80 °C. This device behaviour is normal if a high mains voltage and low insulation fault resistance have been selected.
SERVICE lights up
Overtemperature PGH (isoxx1685DP)
Overtemperature of the locating current injector
• Wait for the end of the cool-down period SERVICE lights up
Check date and time!
Date and time have not been set yet
• Set local date and time
(in case of voltage failure buffer for three days)
