Technical data
85
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
Other
Operating mode ....................................................................................................................................... continuous operation
Position of normal use........................................................................................................... vertical, mains connection on top
Tightening torque of the screws (4x M5) for enclosure mounting..................................................................... 1.0…1.5 Nm
Degree of protection, internal components......................................................................................................................... IP30
Degree of protection, terminals ........................................................................................................................................... IP30
Enclosure material .................................................................................................................................................polycarbonate
Flammability class .................................................................................................................................................................. V-0
Weight ......................................................................................................................................................................... ≤ 1600 g
1.) for U
n
> 500 V no longer acc. to IEC61557-8
12.5 Standards and certifications
The isoxx1685Dx devices were designed according to the following standards:
- DIN EN 61557-8 (VDE 0413-8)
- IEC 61557-8
- IEC 61557-8 Annex C (for Fast 2000 µF profile only)
- DIN EN 61557-9 (VDE 0413-9)
- IEC 61557-9 (not for isoHV1685D)
- IEC 61326-2-4
- DIN EN 60664-1 (VDE 0110-1)
12.6 Ordering details
The values marked with an * are absolute values.
Type
Response value
range
Nominal voltage Supply voltage * Art. No.
iso1685DP-425 200 …1 M
AC 0…1000 V
DC 0
…1500 V
DC 18…30 V B91065802
isoHV1685D-425 200 …1 M
AC 0…2000 V
DC 0…3000 V
DC 18…30 V B91065805
isoLR1685DP-325 20 …100 k
AC 0…690 V
DC 0…690 V
DC 18…30 V B91065803
