Settings
61
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
8.2 (2.7) Inputs
In this menu, each digital input can be configured. For this purpose, select a digital input.
8.2 (2.7.1) Mode
See chapter 8.2 (2.4.3.1) "Mode”.
8.2 (2.7.2) t(on)
Seechapter 8.2 (2.4.3.2) "t(on)”.
8.2 (2.7.3) t(off)
See chapter 8.2 (2.4.3.3) "t(off)”.
8.2 (2.7.4) Function
See chapter 8.2 (2.4.3.4) "Function”.
8.2 (2.8) Device
8.2 (2.8.1) Name
8.2 (2.8.2) Trigger
See chapter 8.2 (2.4.4.3) "Trigger”.
8.2 (2.8.3) Fault memory
See chapter 8.2 (2.4.4.4) "Fault memory”.
8.2 (2.9) Service
The service menu can only be accessed by Bender service staff.
8.2 (3 ) Data measured values
The ISOMETER® stores certain measured values for a specific period of time. These data can be
viewed at the "Data meas. values" menu item. Navigate through the different views using the
and buttons:
•Dig. input 1 (BS 2/1)
•Dig. input 2 (BS 2/2)
•Data - isoGraph Displays the insulation resistance and chronological sequence.
•Data - Insulation Displays the current insulation resistance and the system
leakage capacitance.
•Data - Voltage Displays the system voltages and the partial voltages to earth
•Data - PGH
(isoxx1685DP only)
Displays measuring current, locating current, performance and
insulation fault location mode.
•Data - Temperature Mains connection and locating current injector
