Settings
52
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
8.2 (2.2) Scanning channels
For a successful insulation fault location, all active measuring channels must be determined.
Indicate if you would like to start the search for EDS measuring channels.
Also refer to "Commissioning EDS (isoxx1685DP only)" on page 35.
8.2 (2.3) Activating channels
During initial commissioning all channels are inactive. Before configuring the channels, they
must be activated in this menu. Navigate to the required selection point using the and
buttons. Confirm selection by pressing "OK". Select the measuring channels to be activated
with the button.. Multiple selection is possible here.
8.2 (2.4) Group settings
Use group settings to adjust the settings for several EDS or EDS channels simultaneously or to
read out settings.
If you would like to make settings for each EDS or each EDS channel individually, please refer
to the menus from chapter 8.2 (2.5) "Channel” to chapter 8.2 (2.8) "Device”.
•Cancel Aborts the scan process.
•Start Starts the scan process (search) for EDS channels.
If one bus device fails, the ISOMETER® asks whether it should search for measu-
ring channels and then automatically determines all channels again. Also refer
to
"Alarm messages" from page 74
.
•Select all All channels are selected.
•No selection No channel is selected.
•Invert selection The current selection is inverted.
•Channel 1 (BS 2/1) A single channel is selected.
...
•Channel 12 (BS 2/12)
The values indicated in the group settings are not the values of the indivi-
dual EDS but the factory settings or the last adjusted values in the ISOME-
TER®. To see the values of the individual EDS devices, please navigate to the
menus from
chapter 8.2 (2.5) "Channel”
to
chapter 8.2 (2.8) "Device”
.
