Technical data
80
isoxx1685Dx-x25_D00272_07_M_XXEN/09.2022
12.3 Factory settings
Parameter Value
Response values/alarms
Measurement profile Power circuits
Response value R
an1
(ALARM 1)
40 kΩ
4 kΩ for isoLR1685DP-325
Response value R
an2
(ALARM 2)
10 kΩ
1 kΩ for isoLR1685DP-325
Fault memory off
Coupling monitoring on
Switching elements
Relay 1 (11, 12, 14)
Operating mode: N/C operation
Function: Insulation measurement
Relay 2 (21, 22, 24)
Operating mode: N/C operation
Function: Insulation measurement
Relay 3 (31, 32, 34)
Operating mode: N/C operation
Function: Insulation measurement
Insulation fault location
(isoxx1685DP only)
EDS mode auto
PGH current 25 mA
BMS
BMS address 2
BMS termination ON
Digital inputs
Digital input 1
Operating mode: active high
Function: TEST
Digital input 2
Operating mode: active high
Function: STANDBY
for isoHR1685D-925: "Initial measurement"
Other
Standby mode (disconnection from the
mains)
off
Permissible system leakage capacitance depending on the set measurement profile
Buzzer off
Menu language Deutsch
Password query off
Password 0000
