8.2 (2.4.3) Dig. input
Select the digital inputs of the EDS to be configured:
Afterwards, make the settings for the selected digital inputs of the EDS.
8.2 (2.4.3.1) Mode
The operating mode for the digital input can be set to the values below. For a description, refer
to "Setting the EDS mode (isoxx1685DP only)" on page 33. The following can be selected
:
8.2 (2.4.3.2) t(on)
The response time t(on) after a switch-on signal can be set between 100 milliseconds and 5 mi-
nutes. For a description, refer to "Setting the EDS mode (isoxx1685DP only)" on page 33.
8.2 (2.4.3.3) t(off)
The response time t(off) after a switch-off signal can be set between 100 milliseconds and 5
minutes. For a description, refer to "Setting the EDS mode (isoxx1685DP only)" on page 33.
8.2 (2.4.3.4) Function
8.2 (2.4.4) Device settings
8.2 (2.4.4.1) System type
Adjust the EDS to the IT system to be monitored.
•Select all All digital inputs are selected.
•No selection No digital input is selected.
•Invert selection The current selection is inverted.
•Dig. input 1 (BS 2/1) A single digital input is selected.
•Dig. input 2 (BS 2/2)
•Active high An event is carried out on the falling edge of the digital input (low to high).
•Active low An event is carried out on the falling edge of the digital input (high to low).
•off Digital input without function
•TEST Device self test
•RESET Reset of fault and alarm messages
•Select all All devices are selected.
•No selection No device is selected.
•Invert selection The current selection is inverted.
•BMS bus 2 (1-12)
•DC DC system
•AC Single-phase AC system
•3AC 3AC system
