54 Multifunction Control Panel
®®
z Line Down (Line T.) - The Output will activate for 15 minutes when tel-
ephone-line trouble is detected. If the trouble condition clears, the Output will
restore automatically when the 15 minute interval expires, otherwise, it will
remain active for a further 15 minutes.
z Reset Fire (Fire res) - The Output will activate in Monostable mode each
a ‘Clear Alarm Memory’ operation is requested (PIN required) at a Keypad
which is assigned to one of the Partitions associated with the Output. If the
Output is programmed as N.C., it can be used as the Negative power supply to
the Fire detectors. In fact, the Negative signal will fail for the programmed
‘Monostable Time’ (refer to Outputs Page) each time a ‘Clear Alarm
Memory’ operation is requested, thus allowing the Fire detectors to reset.
z Alarm (Al.r.bel) - The Output will activate when one of its assigned Parti-
tions signals Alarm, and will restore when the Alarm cycle ends.
z Remote Command (Remote) - The Output will activate when the User executes
a command over the phone (the Control panel Answering device must be enabled).
This signal can be used to activate or stop the OC Output over the phone. The Output
(activated over the phone), can also be restored from the Keypad (via a ‘Clear
Alarm Memory’ command). Refer to the User Manual for further details.
z Negligence (Neglig.) - The Output will activate when the Control panel
generates a Negligence event, and will restore when the Alarm memory
resets (via a ‘Clear Alarm Memory’ command).
z Monostable (Monosta.) - The Output will remain active until the ON
Time expires, after which it will be forced to standby for the programmed
OFF Time. The following Table shows the restrictions associated with Out-
puts with this attribute.
0 $*
21#3
'
Chime
Reset Fire
Sqwark
Mute Alarm
Failed Call
Valid Key
Valid code
Superkey 2
Superkey 2 on wireless key
121
'
Trouble
Alarm
Remote Command
Not Ready Stay
Not Ready Away
Restore if in standby
'
121
'
Partitions Armed
Partitions Disarmed
Alarm Memory
Exit Time
Entry Time
Auto-Arm Timeout
Negligence
Not Ready Stay 0 Delay
Line down
Inactivity
False Key
Zone Tamper
System Tamper
BPI Tamper
Missing BPI
