Icon 2000 v4 Profibus EDD for AMS Manual
A
AA
A
© Copyright by BIFFI Italia. All right reserved 234/Rev.1 Page 7
The installation progress bar will be displayed:
5. A termination message will be displayed at the
end of the installation.
Select “Ok” button to terminate.
3.2 EDD Configuration
When an ICON 2000v4 is connected to the profibus network, the actuator will be shown into the “AMS
Device Manager” application as it is shown on figure below:
1. Select the device and press the right button of
the mouse for open the device task list.
Select “Identify PROFIBUS device”.
