4 Configure/Setup
4.1 Overview
This is the first page shown when a double click with the mouse is done on the actuator into the AMS
interface, and displays the more significant status information.
All the displayed data are READ-ONLY and dynamically updated.
Name Description
Actuator Position Actuator Position
Alarm Indicates the presence of an Alarm
Warning Indicates the presence of a Warning
Selector in local The local Selector is in local mode
Selector in Remote The local Selector is in Remote mode
Selector in OFF The local Selector is in OFF mode
