5.4 Maintenance Information / Torque profile
The Torque profile Tab, collect the information about the Icon 2000 v4 torque profile.
All the displayed data are READ-ONLY and static. The data are read from the actuator only when the
window is opened: a ‘Refresh’ button is present for re-read all the data from the actuator.
The page is divided in two areas; one for the “Actual data”, the other for the “Reference data” (data used as
reference). For both areas there are:
Name Description
Opening Break out Max. % of torque to unseat the valve in opening stroke
Opening Peak Max. % of torque when the valve runs from breakout to ending in
opening stroke
Opening Ending Max. % of torque to seat the valve in opening stroke
Date Opening Date of the opening stroke
