Icon 2000 v4 Profibus EDD for AMS Manual
A
AA
A
© Copyright by BIFFI Italia. All right reserved 234/Rev.1 Page 21
6 Process Variables
6.1 Actuator Status
The complete list of the states of the actuator is displayed into this page.
All the displayed states are READ-ONLY and dynamically updated. The followings data are displayed:
Name Description
close limit The Valve is in close position
open limit The Valve is in open position
moving The Valve is moving
monitor relay Monitor relay status
selector in local The Local selector in LOCAL position
selector in remote The Local selector in REMOTE position
alarm Indicates that an alarm is present
warning Indicates that a warning is present
