• Press YES if the position value where pulsing control stops is correct, press NO to scroll
the list of available values. Press YES when the value is correct
• Press YES if the value of the ON time of pulsing control is correct, press NO to scroll the
list of available values. Press YES when the value is correct
• Press YES if the value of the OFF time of pulsing control is correct, press NO to scroll the
list of available values. Press YES when the value is correct
Opening direction
• Press YES if the status is OK, or NO to change. Press YES to confirm (status = On
enables 2-speed timer operation in opening direction; status = Off, disables timer
operation in opening direction).
• Press YES if the position value where pulsing control starts is correct, press NO to scroll
the list of available values. Press YES when the value is correct
• Press YES if the position value where pulsing control stops is correct, press NO to scroll
the list of available values. Press YES when the value is correct
• Press YES if the value of the ON time of pulsing control is correct, press NO to scroll the
list of available values. Press YES when the value is correct
• Press YES if the value of the OFF time of pulsing control is correct, press NO to scroll the
list of available values. Press YES when the value is correct
1.12 BUS (or FDI CONTROL)
This routine is only available if a fieldbus interface card is present. The routine allows setting
the most important parameters (node address, termination, etc.) necessary to connect the
actuator to a fieldbus. If the ICON2000 was set to work with fieldbus, but the fieldbus card is
not present, a Hardware alarm will be generated. Different interfaces are available to
connect the ICON2000 to different types of fieldbus. If the bus interface is LonWorks, the
routine “BUS” changes in “FDI control”. See the specific manuals for instruction and setting
of the above modules.
1.13 MISCELLANEOUS
It includes different types of routines as “time and date”, “factory settings”, “lithium battery”,
“torque profile”, etc. used only for special application or in particular conditions.
1.13.1 TIME AND DATE
Time and date are used in maintenance functions to associate the time information to the
memorised event (torque profile, alarm log, maintenance request, etc.). Time and date are
entered at the time of manufacture, but they can be adjusted during commissioning or
maintenance operations.
Configuration procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and enter the password according to the instructions (see “Entering the set-
up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press YES
to select actuator set-up menu, press NO to scroll the list of available routines and then
press YES to select Miscellaneous.
70
© Copyright by BIFFI Italia. All rights reserved.
“ICON2000”
instruction and operating manual
Section 618/2 chapt. I
