• Press YES to enter the time and date routine.
• Press YES if the time is correct, press NO to change it
• Enter hours, minutes and seconds. Press NO to scroll the list of available values, press
YES to select.
• Press YES when the time is correct
• Press YES if the date is correct, press NO to change
• Enter day, month, and year. Press NO to scroll the list of available values, press YES to
select.
• Press YES if the date is correct
1.13.2 FACTORY SETTINGS
The above routine resets the present configuration and restores the default configuration as
below:
Configuration procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and then enter the password according to the instructions (see “Entering the
set-up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press
YES to select the actuator set-up menu, press NO to scroll the list of available routines
and then press YES to select Miscellaneous.
• Press No to scroll the list of routines and press YES to select factory configuration. Press
YES to download the standard configuration, press NO to exit.
71
© Copyright by BIFFI Italia. All rights reserved.
“ICON2000”
instruction and operating manual
Section 618/2 chapt. I
Section 618/2
stroke limits
Torque set-up
ESD set-up
Remote controls
Locals controls
Output relay
2-speed timer
Miscellaneous
close direction: CW
close limit: by position
open limit: by position
Closing torque: 40%
Opening torque: 40%
ESD action: close
ESD signal: present
ESD priority: ESD < motor thermostat
ESD < torque limit
ESD < local stop
ESD > local controls
ESD > 2-speed timer
ESD < OFF
Control type: 4 wires latched
Control type: latched with instant reverse
LED’s colour: green = open / opening
red = close / closing
yellow = alarm / warning
Default #1
Opening direction: off
Closing direction: off
Lithium battery : absent
Torque profile: standard
torque by-pass: 4%
valve jammed: 4 sec.
