“ICON2000”
instruction and operating manual
Section 618/2 chapt. I
Section 618/2
3.7 SET DATA LOGGER
The “data logger” routine allows to set the data logger parameters (see VIEW mode,
Maintenance, Data Logger, chap L ).
To start the data logger the following data should be set:
Logger mode: recorder, event, off, T-recorder
Sampling time: from 1 to 3600 secs (the sampling time is only used in recorder
mode)
Memory mode: stop when memory is full, continuous stop after overwriting the
memory 5000 times (event) and 10000 times (recorder/T-recorder)
Start date: date when the logger starts
Start time: time when the logger starts
Configuration procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language and then enter the password according to the instructions (see “Entering the
set-up mode”). When the message displayed is “SET-UP MODE OK?” press YES. Press
NO to scroll the list of available menus and then press YES to select maintenance menu.
• Press NO to scroll the list of available routines and then press YES to select “data logger”.
• Press YES if the mode is correct. Press NO to scroll the list of modes and press YES to
select the desired value .
• Press YES if the sampling time is correct. Press NO to scroll the list of times and press
YES to select the desired value.
• Press YES if the memory mode is correct (stop when full or continuous). Press NO to
change and press YES to select.
• Press YES if the start time is correct. Press NO to scroll the list and press YES to select
the desired sampling times (hour, min, sec).
• Press YES if the start date is correct. Press NO to scroll the list and press YES to select
the desired sampling times (day, month, year)
• Press YES to confirm the above settings.
