View procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language according to the instructions (see “Entering the view mode”). When the
message displayed is “VIEW MODE OK?” press YES. Press NO to scroll the list of
available menus and press YES to select the Maintenance menu.
• Press NO to scroll the list of available routines and press YES to select operation log.
• Press YES to select general data or press NO to skip to recent data.
• Press YES to scroll the list of values.
• Press YES to view the recent data log or press NO to exit.
• Press YES to scroll the list of values.
4.5 MAINTENANCE DATE
The routine allows to view the following dates:
• last date
• next date
• start-up date
• recent log date
Last date: this is the date of the last maintenance operation. The date should be updated
by the user after all maintenance operations (see SET-UP menu, maintenance, chap. I).
Next date: this is the date of the next scheduled actuator maintenance. When the date is
reached, the ICON2000 generates a maintenance request warning. The date should be
updated by the user after all maintenance operations (see SET-UP menu, maintenance,
chap. I).
Start-up date: this is the date of actuator start-up. During commissioning, the user
should enter the start-up date (see SET-UP menu, maintenance, chap. I).
Recent log date: This is updated after entering command “Clear recent data log” (see
SET-UP menu, maintenance, chap. I). This command clears the “recent data log”
counters. The content of “recent log” is updated starting from “recent log date”.
View procedure:
• Move the local selector to OFF and then simultaneously press OPEN and STOP. Select
the language according to the instructions (see “Entering the view mode”). When the
message displayed is “VIEW MODE OK?” press YES. Press NO to scroll the list of
available menus and press YES to select the Maintenance menu.
• Press NO to scroll the list of available routines and press YES to select the maintenance
date routine.
• Press YES to scroll the list of dates.
4.6 DATA LOGGER
The “data logger” routine allows to collect different types of data useful in maintenance or in
diagnostic programs. Since the amount of collected data is very large, the data logger can
only be viewed by means of a PDA or PC. The data can be up-loaded from ICON2000 to
PDA or PC by the BLUETOOTH
TM
wireless connection. The local display only allows to view
the value of the configured parameters (see also SET-UP menu, Maintenance, Set data
logger, chap I). The following data can be viewed on the local display:
85
© Copyright by BIFFI Italia. All rights reserved.
“ICON2000”
instruction and operating manual
Section 618/2 chapt. L
