V6 Vital Signs Monitor User’s Manual
4
A.3.6 Input device
Function button
5, NIBP, record, suspend/silence, screen switch and power switch
Knob
With
Barcode scanner
Optional
Temp module
Button
1，START
A.3.7 Connectors
Center computer connector
RJ-45, 10M/100M, TCP/IP
Serial port
RS232 serial port
Nurse call
Nurse call connector
Equipotential grounding
point
1
USB connector
Barcode scanner or other USB devices supported by monitor
SD card connector
reserved connector
Wireless network
reserved connector
Temp module connector
Temp probe connector
A.3.8 Signal Output
Nurse call output
Drive mode
Relay
Electric specification
≤60W、≤2A、≤36VDC、≤25VAC
Isolated voltage
1500VAC
Signal type
N.C., N.O.
A.3.9 Data Storage
Clinic Mode
Patient quantity
1000
Recording number
16000
Single patient clinic
record number
(1-16000)
