Define (Method, Map, Formula and Curve) | 49
ELx800 Operator’s Manual
Plate Type
For 6- to 384-well standard plates, the plate types and sizes included in the
software onboard the ELx800™ are based on the brands listed below. For best
measurement results, use these brands when operating the ELx800 via its onboard
software.
Plate Type Brand
6-well Costar
12-well Corning
24-well Corning
48-well Costar
96-well Costar
384-well
Nunc square
*
96 T
Terasaki
*
72 T
Terasaki
*
60 T
Terasaki
*
*Used only on ELx800NB version
The PLATE TYPE selection screen allows you to select the geometry of the plate
that will be used for the assay. Press *MORE to cycle through the available options.
Note: The NB version of the reader includes choices for 384-well, or
72- and 96-well Terasaki plate formats. An adapter (PN 7330531) is
available from BioTek if Terasaki plates are to be used with the NB
reader.
P L A T E T YPE: 96 WELLS
2 4 4 8 9 6 3 8 4
P L A T E T YPE: 96 WE L L S
6 1 2 2 4 * M O R E
