SECTION 2 INSTALLATION AND PREPARATION FOR USE
______________________________________________________________________
2-6
2.3 The BIS VISTA Monitoring System –
Equipment and Supplies
The BIS VISTA Monitoring System consists of the following basic components:
• BIS VISTA Monitor (P/N 185-0151)
• BISx (P/N 185-0145-AMS)
• Patient Interface Cable (PIC) (P/N 186-0107)
• BIS Sensor
• Detachable Power Cord
Sensors are sold separately. For a list of available sensors please contact Aspect Medical
Systems, Inc. or your local distributor.
A pole clamp is also included; however its use is optional. Contact Aspect or your local
representative for information on additional equipment and accessories.
Figure 3 - The BIS VISTA Monitoring System
BIS Sensor
Patient Interface
Cable (PIC)
BISx
Monitor
Interface
Cable
BIS VISTA Monitor
ON/Standby
Button
