Bizerba eS10 User Manual

Technical data Operating instructions eS10
98 38034911005 en
13
13.5 Power supply
Supply voltage: Default:
100 – 240 V AC, 50 – 60 Hz, 0.4 – 0.2 A
Optional batter pack:
220 – 240 V AC, 50 – 60 Hz, 0.2 A
100 – 120 V AC, 50 – 60 Hz, 0.4 A
Battery pack (optional): 10.8 V / 4.4 Ah (operating time: 20 h)
Device fuse: T 1.6 A
13.6 Protection class
Terminal: IP65/IP69K
Standard load cell: IP54
Stainless steel load cell: IP68/IP69K
13.7 Interfaces
– RS232
– PIO
– Outputs with open collector (open collector switch)
– Ethernet
13.7.1 Parallel inputs and outputs
The connection of parallel inputs and outputs includes 4 outputs and 3 inputs. This is a 16-
pin connection.
All information refers to ±0 V, grounded.
Outputs
Open collector outputs; max. 24 V, 30 mA
Pin No.
Name Function
3 Channel 1 output Lower tolerance limit
5 Channel 2 output Target value
7 Channel 3 output Upper tolerance limit
9 Channel 4 output Scale in no-motion condition
Voltage range for logic 1: +4.6 V – +5.8 V
Voltage range for logic 0: ±0 V – +0.5 V

Bizerba eS10 Specifications

General

Brand	Bizerba
Model	eS10
Category	Scales
Language	English
