63–
40) Set the zone width of peak search
Command: PKWIDTH
*******
(
*******
=Refer to [24.4 Input the frequency])
41) Set the unit of marker
Command: CONV
***
(
***
=DBM, M, DBV, V, DBUVM, VM)
42) Request the transfer of hard copy
Command: PRT
*When transferring the returned data to optional printer, hard copy is performed．
43) Request to transfer trace
Command: SRS
****
(
****
=CURR, 00 to 99)
44) Request to transfer 1001 date of trace
Command: SRSF
(Refer to “24.3 Transfer the data” about returned data.)
45) Request the preset
Command: PRESET
46) Set the remote control
Command: REMOTE
***
(
***
=ON, OFF)
47) Single sweep
Command: CAPT
* It sweeps only once and will be in a HOLD state.
48) Setting of the offset level
Command: OFFSET
****
(
****
=-50.0 to 50.0 [0.1step, unit:dB])
49) Setting the input impedance
Command: IMP
**
(
**
=50, 75)
* When selecting of “75Ω”, please attach the coaxial connector (impedance converter) MA301 (optional)
to an input connector.
Command Unit of marker
DBM dBm
W W
DBV dBV
V V
DBUVM dBµV/m
VM V/m
Command Trace that is transferd
CURR Trace of Current
00 Trace of save data 1
··· ···
99 Trace of save data 100
Command Remote control
ON
Any operation from the keys or the
encoder of the main body will not
be accepted. Control the unit with
RS-232C commands.
OFF
The operation from the keys or the
encoder of the main body and
RS-232C commands will be accepted.
* When remote control is ON, “REMOTE”
is displayed in the operating information
display area on the LCD screen.
(Refer to “4. Description Of Screen” for details)
Command Offset level
50 Offset level is set to 0dB.
75 Offset level is set to 5.7dB.
