SERVSWITCH™ OCTET INSTALLER/USER GUIDE
26
Figure 3.1 illustrates one possible switching system configuration using SAM and
Serial SAM modules.
Figure 3.1: Octet Switching System Configuration with SAMs and Serial SAMs
Octet Switch (KV1701A/E Switch Shown)
Octet User Station
(KV1713 User Station Shown)
Serial SAM
Local PC
SAM
(PS/2 Shown)
Server with
Octoware Software
USB Keyboard
and Mouse
Serial Device
Stereo Speakers
and Microphone
Monitor
Target Devices
Serial Port
