CHAPTER 6: USING SERIAL SAMS
93
Language support
The Serial SAM is designed to operate correctly with all of the keyboard layouts that are
selectable on the KV171xA user station. Once a keyboard layout in the OSD is selected,
the Serial SAM ensures that the correct character for the key pressed is passed to the serial
device. This is done automatically and does not require any intervention from the user.
DB9-F
Host Signal
Name/Description
Signal Flow SRL Signal Name/Description
8 CTS - Clear to Send Out of SRL RTS - Request to Send
9 N/C - Not Connected N/A N/C - Not Connected
Serial SAM Pinouts (Continued)
