CHAPTER 4: OPERATIONS
65
Keyboard type
If you connected a PS/2, USB or Devlin Vizrt keyboard to the user station, you will not
have to change the keyboard type. If you connected a Pinnacle FAK or Chyron Duet
keyboard to the user station, complete the following steps to set the keyboard type.
To set the keyboard type on the user station:
1. Press Ctrl+Ctrl to launch the OSD.
2. Click the Console tab, then click the down arrow button to display the
Configure screen.
3. The Type field displays the current keyboard type. The Type field changes to PS/2
Type if your Octet switching system includes an KV1713A/E user station.
The Type or PS/2 Type field is activated if your Octet switching system includes an
KV1712A/E/KV1713A/E user station connected to a PS/2 keyboard. The Type or
PS/2 Type field is deactivated in the following cases:
• Your system includes a KV1711A/E user station and is connected to a PS/2 key-
board. In this case, Standard is displayed in the Type field.
• Your system includes any version of the Octet user station and is connected to a
Sun keyboard. In this case, Sun is displayed in the Type field.
If the Type or PS/2 Type field is activated, select Standard, Pinnacle FAK or Chyron.
The change will be highlighted in blue text.
Dutch Spanish
Finnish Swedish
French Swiss-French
German Swiss-German
Greek Taiwanese
Italian United Kingdom
Japanese
Available Keyboard Layouts on USB and Sun Octet Access Modules
Keyboard Layouts
