Blackmagicdesign Videohub User Manual

Contents
Videohub Software Control Manual
4 Getting Started
Introducing Blackmagic Videohub Control 4
Installing Videohub Control 4
Mac OS X installation 4
Windows installation 4
5 Using Blackmagic Videohub
Videohub Control
Getting to Know the Interface 6
Menus and Buttons Explained 7
Settings Menu 7
Edit Buttons 7
Using Pushbuttons 8
Viewing and Switching Routes 9
Locking and Unlocking Routes 10
11 Help
12 Warranty

Blackmagicdesign Videohub Specifications

General

Video Input	SDI
Video Output	SDI
Serial Router Control	RS-422
Ethernet Router Control	10/100/1000 Ethernet
Inputs	40
Outputs	40
SDI Bit Depth	10-bit
Power Supply	Internal power supply, 100-240V AC
