Blackmagicdesign Videohub User Manual

Contents
Videohub Hardware Control Manual
4 Getting Started
Introducing Videohub Controllers 4
Videohub Master Control 4
Videohub Smart Control 4
GPI and Tally Interface 4
Connecting USB to Setup the Control Panel 5
Plugging into an Ethernet Network 5
Control Panel Button Diagnostics 6
Installing the Videohub Software 7
Mac OS X installation 7
Windows installation 7
Setting up your Videohub Controller 8
Configuring Videohub Master Control 9
Configuring Videohub Smart Control 10
Setting up the GPI and Tally Interface 12
Configuring the GPI and Tally Interface 12
Labeling Pushbuttons 13
14 Using Videohub Master Control
About Routing Levels 14
How to Select Sources and Destinations 14
20 Using Videohub Smart Control
Using Videohub Smart Control as a Cut-Bus Controller 20
Using Videohub Smart Control as an XY Controller 20
21 Using GPI and Tally Interface
Configuring GPIs 21
Configuring Tally 21
23 Help
24 Warranty

Blackmagicdesign Videohub Specifications

General

Video Input	SDI
Video Output	SDI
Serial Router Control	RS-422
Ethernet Router Control	10/100/1000 Ethernet
Inputs	40
Outputs	40
SDI Bit Depth	10-bit
Power Supply	Internal power supply, 100-240V AC
