CAUTION!
It is essential for this application that the deceleration switches S81
and S82 are mounted at the proper deceleration points and function
perfectly.
Deceleration of a travel at maximum speed must set on at these
deceleration points and the flush-level position of the terminal land-
ings must not be over-travelled.
Deceleration is initiated when the switches in the direction of travel
open accordingly.
Deceleration switch S81 is related to upward travel and opens to
switch the lift to low speed (V0) before reaching the top landing.
Deceleration switch S82 is related to downward travel and opens to
switch the lift to low speed (V0) before reaching the bottom landing.
Settings in the setup menu: > FUNCTIONS
> FLOOR SELECTOR
> DECELERATION (S81/82)
ON
102 Installation Manual System »bp308« – Commissioning Instructions
