Description Symbol Unit XMQ1-WQ001
Minimum distance on the top of
the device
4)
d
top
mm 80
Minimum distance on the bottom
of the device
5)
d
bot
mm 80
Horizontal spacing at the device
6)
d
hor
mm
0 (for devices in the DC bus group)
10 (for devices outside of the DC bus group)
Rated control voltage input
7)
U
N3
V 24
Rated power consumption control
voltage input at U
N3
8)
P
N3
W 288
Short circuit current rating SCCR A rms 42000
Rated input voltage, power
9)
U
LN_nom
V DC 254 ... 750
Rated input current
I
LN
A DC 64
Required wire size in accordance
with NFPA 79 and UL 508 A
(internal wiring);
10)
A
LN
AWG
Axis 1: 8
Axis 2: 10
Axis 3: 14
Axis 4: 14
Field wiring material (material;
conductor temperature; class)
Cu; 75 °C; 1
Output voltage
U
out
V AC 0 ... 500
Output current
I
out
A
Axis 1: AC 27
Axis 2: AC 18
Axis 3: AC 6.7
Axis 4: AC 3.3
Output frequency range
11)
f
out
Hz 0 ... 1600
1) 2) 3) Housing dimensions
4) 5) 6) See fig. "Air intake and air outlet at device"
7) Observe supply voltage for motor holding brake
8) See information on "Rated power consumption control voltage
input at U
N3
"
9) Mains input L1, L2, L3; For use on a solidly grounded wye
source only.
10) Copper wire; PVC-insulation (conductor temperature 75 °C;
T
a
≤ 40 °C) in accordance with NFPA 79 chapter 12 and
UL 508A chapter 28
11) Depending on switching frequency which was set in parameter
P‑0‑0001
Tab. 7-3: UL ratings and dimensions
Rated power consumption control voltage input at U
N3
Plus motor holding brake and control section, plus safety option
