4-1
Bosch Security Systems 05/10 BLCC100I
SE CT IO N 4

T
he Solution 16
plus
Control System incorporates a menu text
driven interface. This interface is very similar to that found
on many mobile phones. Once programming mode is entered
you will see a number of menu options in the display and these
may vary depending in the user authority level.
ENT ERI NG PRO G RA MMI NG MOD E
To enter installer program mode enter, PIN + [MENU].
The default Installer PIN is 1234.
The Red and Green LED indicators on the keypad will ash to
conrm Installer programming mode is active.
i
Note
All areas must be disarmed with no active alarms. To disarm all
areas enter the Installer PIN and hold the [OFF] Key for 2 seconds.
EXI TIN G P ROG R AM MIN G M ODE
Press and hold down [MENU] key for 2 seconds.
The system will scan all schedules and peform the functions
relative to the current system. For example if a timed output
should be operated then it will operate and if the system should
be armed it will arm.
i
Note
You can also select Exit and press [OK] from each menu level.
COMM AND ME NUS
When you rst enter programming mode a special menu called
the Command Menu will appear at the top of the menu tree.
The Command Menu provides a list of the most common
system funtions like “Turn Chime Mode On”, “Move To An Area
or Turn An Area On.
Use the up and down arrow keys to navigate and press [OK] to
select the command.
PRO G RA M MI N G OPT ION BI T M EN U S
Use the up and down arrow keys to scroll through the 8 dierent
options. To enable an option, press the [ON] key – a tick will be
displayed. To disable an option, press the [OFF] key.
Off On Low Battery
Show Overload
Report Overload
Press
 OK ON OFF MENU
To save programming changes, press [OK] or press [MENU] to
exit without saving.
NAV IGAT I NG TH E M ENU S
Using the up and down arrow keys to navigate, locate the
desired menu item using the highlight bar and then press the
[OK] key to select.
A new list of menu items will appear. Repeat the above until the
desired menu item is located.
To navigate backwards through the menu items press the
[MENU] key at any time. Alternatively if you know the direct
menu item number press [MENU] + Item Number.
Key Description
Scrolls Cursor Left
Scrolls Cursor Right
Scrolls Cursor Up
Scrolls Cursor Down
 Enter Menu Options or Saves Changes

Go Back One Level, Abort Current Change or
Hold Down to Exit Programming Mode
 Enter Data Value
 Turn On Bit Option
 Turn O Bit Option, Clear to End of Line
Table 12: Keys Used During Programming
LIS T O P TI O NS
Use the up and down arrow keys to step through the available
options. Press [OK] to save or [MENU] to exit without saving.
ZONE TYPE ZN001
01 - Burglary Delay 1
PRESS
 0-9, OK or MENU
i
Note
You can also enter the option number directly followed by [OK].
You must press the [OK] a second time to conrm the current
setting.
