 Installation Manual  Programming Overview
DT M F C O NT ROL FU N CT I ON S
The control panel includes comprehensive DTMF control of
individual areas and outputs with full user PIN and TIMER
GROUP access verication.
Unlike other systems, no additional hardware or modules are
required for DTMF control. To congure the desired functions
see MENU 5-3-5 DTMF Options.
How to Use DTMF Control
1. Once the panel answers the incoming call, if either option 1,
2, 3 or 4 in MENU 5-3-5 is enabled, then the panel will play a
short welcome jingle. You now have approximately 5 seconds
to enter a valid PIN and log onto the panel.
2. Enter PIN followed by the # key. If the PIN is valid the system
will respond with two short beeps. If the PIN is invalid then a
single long beep will be heard.
If a valid PIN is not entered in time, the panel will attempt
to establish a modem connection as if connecting to the
SolutionLink software.
If this happens you will need to hang up for approximately 60
seconds before trying again.
3. Once validated, the following commands can be performed.
See the table below. If no keys are pressed for 20 seconds then
the panel will play the exit jingle before terminating the session
and hanging up. Pressing ## at any time while connected will
cause the panel to terminate the session.
DTMF CONTROL FU NC TI ONS
Operation Command Response
Quick Arm
All Areas
0 + #
2 x Beeps
Log In
OK
USER PIN + #
Welcome
Jingle
Log In
Failed
USER PIN + #
Long Beep
Turn Area
ON
1 + (Area Nº1-8) + 1 + #
2 x Beeps
(Low - High)
Turn Area
OFF
1 + (Area Nº1-8) + 2 + #
2 x Beeps
(High - Low)
Turn Output
ON
2 + (Output Nº1-16) + 1 + #
2 x Beeps
(Low - High)
Turn Output
OFF
2 + (Output Nº1-16) + 2 + #
2 x Beeps
(High - Low)
End
Session
# + #
Exit Jingle
Table 17: DTMF Remote Control Functions
DTMF EXA MPL ES
Each example below shows the log on step for clarity. In practise
is only necessary to log on once per DTMF control session.
To turn Area 1 ON enter the following
2 + 5 + 8 + 0 + #
= Log ON
1 + 1 + 1 + #
= Arm Area 1
To turn Output 10 ON enter the following
2 + 5 + 8 + 0 + #
= Log ON
2 + 10 + 1 + #
= Turn Output 10 ON
To turn Output 12 OFF enter the following
2 + 5 + 8 + 0 + #
= Log ON
2 + 12 + 2 + #
= Turn Output 12 OFF
i
Note
If the DTMF Quick Arm option is enabled then it is possible to
remotely arm all areas without logging onto the panel.
Simply enter 0 + # following the welcome jingle.
Make sure that the phone being used to remotely control the
panel is set to transmit DTMF tones when keys are pressed
during the call. This option is disabled by default on some
phones.
