8-8
Bosch Security Systems 05/10 BLCC100I
Solution 16
plus
Installation Manual Output Programming
New - Software Version 1.02 and later sounds an alarm when the
system is armed or disarmed. Previous software versions would
only sound an alarm when the system was armed?
Block If All On
This option prevents the output from turning on when the
corresponding area is turned All On. When the area is o, Part On
or Part 2 On, the output can again operate when the output event
occurs.
Display Status Message
This option allows the keypad to display the output that is currently
active on the keypad.
Outputs > Properties >
Macro Group
MENU 4-1-6
Reserved
OUT PUT TE STI N G
Outputs > Testing >
External Siren Test
-
MENU 4-9-0
This menu allows you to test the operation of any output
programmed as event type 36 (External Audible) or Event Type
36 (Fire Alarm) for 5 seconds.
1) Enter [MENU] + [4] + [9] + [0] and select the area you want to
test the external sirens in from the list then press [OK].
A001 Area 1 Name
A002 Area 2 Name
A003 Area 3 Name
Press OK or MENU
2) Any outputs programmed for event type 36 or 39 in the chosen
area will now operate. The keypad will display the following
during the siren test.
External Audible Testing
Press any key to abort
Press OK or MENU
3) When the siren test is complete, the keypad will display the
following:
Testing Complete. Press
OK to continue
Press OK or MENU
4) Press [OK] to exit.
Outputs > Testing >
Internal Bell Test
-
MENU 4-9-1
This menu allows you to test any output programmed as event
type 37 (Internal Audible) or event type 39 (Fire Alarm) for 5
seconds.
1) Enter [MENU] + [4] + [9] + [1] and select the area you want to
test the internal sirens in from the list then press [OK].
A001 Area 1 Name
A002 Area 2 Name
A003 Area 3 Name
Press OK or MENU
2) Any outputs programmed for event type 37 or 39 in the chosen
area will now operate. The keypad will display the following
during the siren test.
Internal Audible Testing
Press any key to abort
Press OK or MENU
3) When the bell test is complete, the keypad will display the
testing complete message.
4) Press [OK] to exit.
Outputs > Testing >
Strobe Siren Test
-
MENU 4-9-2
This menu allows you to test the any outputs programmed as
event type 48, Strobe light. This test is not timed and needs to
be manually stopped when testing is completed.
1) Enter [MENU] + [4] + [9] + [2] and select the area you want to
test the strobe lights in from the list then press [OK].
A001 Area 1 Name
A002 Area 2 Name
A003 Area 3 Name
Press OK or MENU
2) Any outputs programmed for event type 48 in the chosen area
will now operate. The keypad will display the following during
the siren test.
Strobe Activated. Will
Reset On Exit
Press OK or MENU
3) Check and verify that the strobe lights are working correctly
then press [OK] to end the test.
