Installation Manual Programming Overview
ALP HA TEX T
Text descriptions are available for Area Name, Zone Name, User
Name, Schedule Name, Holiday Name, Prox Reader Name and
Output Name. Each name can have a maximum of 16 characters.
Area 2 Name
Reception Area
PRESS ◄►
, OK or MENU
When programming text, each numeric key represents a
dierent group of characters.
Pressing the same numeric key repeatedly will step you through
the available characters assigned to the key. The text key layout
is the same as most phones. Refer to the table below for detailed
character information.
Key Characters Assigned To Each Numeric Key
1 . , ? ! - & ` 1
2 A B C a b c 2
3 D E F d e f 3
4 G H I g h i 4
5 J K L j k l 5
6 M N O m n o 6
7 P Q R S p q r s 7
8 T U V t u v 8
9 W X Y Z w x y z 9
0 SPACE 0
Scroll Up through entire character list
Scroll Down through entire character list
Move to left one character position
Move to right one character position
OFF Clear from cursor postiion to end of line
Table 13: Text Keypad Character Set
Once the desired character is displayed press the right arrow
key to move to the next character position.
To save programming changes, press [OK] or press [MENU] to
exit without saving.
The following additional special characters are
available by scrolling using the up and down arrow keys.
+ - @ # $ “ & % * : ( ) / < > =
CLO C K PRO G RA M MI N G
Use the left and right arrow keys to move to the eld and use
the up and down keys to change. Press [OK] to save or [MENU]
to exit without saving.
Scroll through the hours to change from am to pm.
SET DATE AND TIME
i01-Jan-2007 12:00 am
PRESS
, OK or MENU
TEL EPH ONE NU MB E RS
To program, select primary telephone number under MENU
5-1-1 then enter the digits of the telephone number and press
the [OK] key to save.
Use the up and down arrow keys to program special characters
(•, # and Pause).
PRIMARY DEST 1 P001
0297417000
PRESS
0-9, OK or MENU
Key Characters Assigned To Each Numeric Key
0 to 9 Enter the Digits 0 to 9
Scroll Up through entire character list 0 - 9 • # ,
comma = 2 second pause
Move to left or right one character position
OFF Clear from cursor position to end of line
Table 14: Phone Number Character Set
To save programming changes, press [OK] or press [MENU] to
exit without saving.
GET TIN G S TA RT ED BAC K TO B AS E
The following steps are the mimimum requirements to get the
system reporting back to base. Examples assume the panel is
disarmed with no alarms and starting from the factory default
settings.
1) Enter Program mode.
[1234 + MENU]
2) Set Time and Date.
[MENU 7-1-0]
3) Change Default Installer PIN.
[MENU 1-5-2]
4) Change Default Master Code PIN.
[MENU 1-1-1]
5) Enter Account (client) Number, Area 1.
[MENU 2-2-0]
6) Enter Base Primary Telephone Number.
[MENU 5-1-1]
7) Enter Base Secondary Telephone Number.
[MENU 5-1-2]
8) Hold Down MENU For 2 Seconds To Exit.
9) SERVICE MODE
Service mode when activated disables dialler reporting, prevents
all alarms and prevents all users from arming the system.
To Next Page
