Bosch Solution 16plus Installation Manual

11-1
Bosch Security Systems 05/10 BLCC100I

SE CT IO N 1 1
 
T
his section contains the dierent parameters required that
are system related features.
The commands menu will allow you to view the panel status,
system troubles, history log, factory default and entering service
mode.
Some of the key parameters in these menus are the setting of
the date/time under Clock and Schedules which control all the
automated time functions of the system.
SYSTE M CO M MA NDS
System > Commands >
Panel Status

-

-

MENU 7-0-0
This command displays the following panel related information
on the keypad display.
Line 1 Displays:
The panel number that you are getting information from (eg.
Node 1 = Panel 1 etc). The Solution 16
plus
is only congured to
work with one panel.
Line 2 Displays:
The panel name and rmware version number.
Line 3 Displays:
The current panel temperature, panel power supply voltage
and any system troubles which are in eect. This line scrolls all
events continiously
1) Press [MENU] + [7] + [0] + [0] to view the panel status.
Panel 001 P001
Solution 16PLUS V1.11
Temperature 28˚C
Press OK or MENU
2) Press [OK] to exit when nished.
System > Commands >
System Trouble

-

-

MENU 7-0-1
This command lists any system troubles which are currently
in eect on the system. Information is diplayed in a list format
allowing you to select a paticular event and then drill down to
view more specic information.
System trouble events such as Failure To Comminicate or Telco
Line Fail are grouped under System Trouble in the list while
open zones are displayed individually one per line.
When the keypad is in standby mode, system troubles and open
zones will be displayed on the status line of the keypad. From
this mode you can access the list of troubles by pressing the
down arrow.
1) Press [MENU] + [7] + [0] + [1] and use the up and down arrows
to highlight the trouble event in the list then press [OK].
P001 System Trouble
Zn001 Zone 1 Name
Zn002 Zone 2 Name
Press  OK or MENU
2) Selecting System Trouble from the list will show the specic
panel version information to be displayed in the rst two lines
while the third line of the display will scroll all current system
trouble events.
Panel 001 P001
Solution 16PLUS V1.11
Date and Time
Press  OK or MENU
3) Selecting a Zone from the list will show the currrent zone state.
Zone 1 Zame Zn001
EOL=Open 53020 ohms
Press OK or MENU
4) If no System Troubles are in eect the keypad will display.
There are no
System troubles
Press  OK or MENU
5) Press [OK] or [MENU] when nished.
i
Note
When in stand-by mode keypads will display system trouble
events on the third line of the display.
