Description
3.4 Technical data
Raw material:
max. breadth 200 mm
max. thickness 15 mm
max. length arbitrarily mm at adapted roller race
length.
Machined part:
max. length 2000 mm on use the tilting table.
max. length 9999 mm with switched off tilting
table and unloading by
hand.
Cylinder:
Cutting pressure 1 x 40 t
Stroke 35 mm
Tool:
Punching tool 4 x AMADA B - station
max. punching diameter 4 x Ø 31,7 mm
rather each form within Ø 31,7 mm
Cutting station 60 x 8 mm
Run height tool 20 mm
Guidance:
Traverse path Y 870 mm
Traverse path X 2010 mm
Machine dimensions:
Length of machine 6610 mm (3m roller table)
9110 mm (6m roller table)
Breadth of machine 2240 mm
Height of machine 1825 mm
Total length 8000 mm (3m roller table)
10500 mm (6m roller table)
Total breadth 3580 mm
Totol height 1825 mm
Weight of machine t
