1 2 3
9.1 Assembly of the pneumatic unit
Pneumatic
Pos. 1 Filter/pressure-regulator unit part number: 9425 2233
Pos. 2 3/2 - valve part number: 9425 2220
Pos. 3 4/2 - valve part number: 9425 2220
tilting table (Pos. 3)
sprayer (Pos. 2)
