Mechanic
5.11 Clamp
Subassembly clamp 614 05036
carriage 1
carriage 2
Setting up of clamp:
- The hydraulic clamping way of the clamping device amounts to 14 mm.
- By means of the index disks the opening of the clamp can be shifted in 10 mm
rasters.
All widths of material upto max. 200 mm can be clamped.
