6.6 Starting the machine
Commissioning
the machine
* Program punching procedure and start the program sequence.
* Insert the tools, requested by the control, and confirm them in the program.
* Now the Y-axis will be moved by the control until the zero-point will be in direction of
material flow from the CU-flat.
* The CU-flat has to be moved by hand between the preseted clamping jaws andmust
attach zero-point X.
* By operation of the foot switch the CU-flat will be clamped hydraulically.
* The operator steps behind the light barrier, confirms these with „RESET light barrier“
and starts the processing of the CU-flat.
* The Y-axis moves to the first punching position selected by program.
* The X-clamp (clamping device) drives forward beyond the end of the CU-flat and
clamps the material.
* The clamping arrangement work piece opens and the X-clamps drives to the 1st
punching position.
* The clamping arrangement work piece closes again.
* Now the punching station is ready. If these punching position is outside the stripper
from the selected tool the punching will done.
* If the punching position is inside the stripper the X-clamp open and moves back.
* The punching will be done.
* The X-clamp drives forward and catches the CU-flat.
* The clamping opens and the next X-position will be driven on.
