Pneumatic
9.3 Pneumatic diagram sprayer
Pos. 1 3/2 - port valve part number: 9425 2220
Pos. 2 Single-sprayer, complete part number: 9465 0001
Pos. 3 TC - non return valve part number: 9465 0004
Pos. 4 Retrofit kit part number: 9465 0003
Pos. 5 Spray head part number: 9465 0002
