Information
6.2.2 The operator´s controls on the control desk
4. The EMERGENCY-OFF button.
Actuate this button only in emergency cases.
5. The touch button for lifting the punch.
6. The touch buttons for lowering the punch.
Two-hand actuation.
6.2.3 The foot pedal for the hydraulic material clamping
This pedal switch serves the hydraulic material
clamping at the inlet side of the machine.
It is released by the control for clamping the material:
- By actuating the foot pedal, the material will be
clamped between the mobile and the fixed clamping
jaw.
